Piping Rear Lid for 1999 Mercedes-Benz SLK 230
No.
Part # / Description / Price
Price
10
Wiring Harness
Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER F298214, ORDER PART NUMBER W/O ES1
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
Description: Trunk lid.
10
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER F298214, ORDER PART NUMBER W/O ES1
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
AS OF IDENT. NUMBER F298215, ORDER PART NUMBER WITH ES1 98
Description: Trunk lid.
60
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 0,5-1,0 MM2, TO 032 545 19 28. 0.5-1.0 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO A 029 545 19 28. 0.5-1.0 MM2 ...
MSRP $5.75
$4.32
MSRP $5.75
$4.32
80
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.24
MSRP $9.50
$7.24
100
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 4 MM. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. 2,5 (AX). 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Ma ...
MSRP $2.90
$2.16
MSRP $2.90
$2.16
120
Receptacle Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 1.5-2.5 MM2 FF6.3Leitungsquerschnitt Min/Max: 1,0-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: FFModel 2: 6.3. TO 001 545 10 28,012 545 31 28. 1.5-2.5 MM2 FF6.3Leitungsquerschnitt Min/Max: 1,0-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: ...
MSRP $2.70
$2.03
MSRP $2.70
$2.03
